The main features of HF system:

Four axis linkage control, under the special surface machining; the Painting Schema automatic programming; processing programmable; with AUOTCAD, AUTOP data interface; machining path, data processing and real-time display; memory blackouts and power recovery processing; two different types of processing card allows users of arbitrary choice, two kinds of different processing methods allow users to easily character and expand the processing object; processing control is stable and reliable, easy to use, friendly interface, the control software and PC card using a combination of control is future line cutting of the leading development direction.

The HF system provides a good operating platform to meet the requirements of all aspects of programming:
(1) The calculation method of geometric elements with different attributes (point, line, circle, arc) is more accurate and smooth than CAD.
(2) powerful graphics exchange ability with AutoCAD, which can read R12 and any version of DXF files, filter and correct DXF duplicate lines, and automatically correct design base points based on DXF when calling.
(3) it has its own CAD font library and HGD font library (International font library of all kinds of fonts), which can easily process all kinds of Chinese characters and Western characters.
(4) The G code generated by any slow, medium and fast wire is converted to HGT, and the G code of HF processing is generated according to the process requirements.
(5) it has rich functions of common curve library and formula curve processing, such as involute gear (variable tooth position, spline gear, small module gear, rack, etc.), cycloid gear, sprocket, indexing cam and non-circular pitch curve cam, etc. For formula curve, we can deal with general formula curve and derived formula curve.
(6) convenient block transformation function and practical measurement and bisection function.
(7) unlimited data storage, convenient and quick to call the file in visual state, can generate plane G code and general taper and variable taper machining list, and has the function of different surface synthesis.
(8) It has stable multiple cutting, concave die step height and width settings, punch tool length and other excellent function settings.
(9) G code generation mode diversification, and has HF patent step wall function, let the workpiece more fine and perfect.
(10) HF software includes ISA, PCI control, servo card, expansion card, electronic hand wheel and other equipment, which makes the man-machine effect of multiple cutting more powerful.
(11) TAC multiple cutting automatic pause and user-defined pause delay time, TA1 multiple cutting the first lap to complete the automatic pause function.
(12) auxiliary settings include system restore, backup, shutdown, startup, partition, multiple startup, disk check, bottom configuration and self startup.
(13) Isa-usb and pci-usb cards support the bottom layer plug and play USB devices of industrial control host.
(14) real time display of group number in multiple cutting, synchronous real-time sending of serial port and control card parameters through serial port dynamic library chain, and customer demand of expanding group number parameters over 15 types can be sent through serial port parameters.
(15) the interface of programming, certificate of deposit, postposition and processing can be easily and quickly switched freely, and the indication of certificate of deposit type is clear.
(16) the electronic handwheel can resist electromagnetic and echo interference in normal and fault-tolerant mode, and can carry out fault-tolerant and filtering correction for other abnormal interference situations.
(17) The servo motor uses the electronic hand wheel and the automatic motor in the cutting state to rise and fall at a constant speed and run at full high speed.
(18) the switch button can be set separately for wire transportation and water supply, and it can also be turned on automatically when cutting to ensure the different needs of customers.
(19) it has G00 code cutting protection and automatic single section idling ability, as well as automatic reverse automatic idling ability after cutting.
(20) It can automatically cut, adjust and correct the main board with unstable clock frequency, query the real-time coordinates of the control card for accurate positioning, and have the ability to export processing graphics.
(21) z-axis table rotation with serial port parameter sending can process 3D solid and special needs workpiece through z-axis rotation.
(22) real time compensation and user-defined real-time compensation can be used in processing, which is convenient for users to modify the compensation coefficient in real time.
(23) up to 15 kinds of parameters (pulse width, pulse current, high frequency power, inverter value, inverter value, etc.) can be set arbitrarily for 1-7 times group number processing.
(24) efficiency comparison is displayed in real time during machining, and the remaining time of both Secant and reverse cutting is automatically displayed through RTS, which is convenient for users to understand the current effective efficiency and required working time.
(25) "sub control center" includes advanced functions, such as "self reverse idling after cutting", "returning to the origin after cutting straight line", "cutting off system machine tool", "automatic repeated cutting", "automatic continuous cutting of multiple graphs", "idling section in graph", etc.
(26) "automatic repeated cutting" adapts to the on-line operation of manipulator and fully automatic repeated cutting, and includes real-time view of sub, repeated times, signal waiting time, and whether the pause character is effectively set.
(27) "multi graph automatic continuous cutting" can set multi graph combination continuous combination cutting, and each graph can be independently configured with high frequency parameter file and G00 effect setting.
(28) "empty section in graph" can set any single graph and composite graph, empty section and G00 effect setting.
(29) "other functions" also include "processing graphics export", "bottom configuration clear", "bottom drive configuration", "control card xyuvz coordinate value", "setting HF exit shutdown" and other functions.
(30) large graphics, frequent code conversion, super large code and G code optimization make the processing stable and reliable and the workpiece more exquisite.
(31) quick installation capability and embedded function at the bottom of the system, as well as more exquisite startup interface to show business value and product publicity.

HF machining precision is high:

In programming, the HF system adopts double precision calculation; HF system generated by the processing code using absolute G code, the numerical precision for retention to the fourth decimal place; HF system in the processing of trajectory when taking a slash, the synchronous mode of two axis (XY UV); HF system on the great circle arc radius not add restrictions. HF software processing through the double error correction, to avoid processing because of the impact of the outside world and lead to data errors. Practice has proved that these methods can effectively eliminate the cumulative error, and from the micro to reduce the processing error, and to a certain extent, improve the finish, improve the processing efficiency. HF is not only reflected in the processing of silk processing software features, but also in the process of silk processing is more slowly in the fine, fine fine, the product has been the world's attention in the international exhibition.

The most distinctive features of HF system in the processing of pyramidal and ISO surface:

Processing all kinds of cone and different surface is one of the characteristics of HF system. In the ISO surface volume synthesis, in accordance with section synthesis and according to the length of synthesis, and can immediately simulation of cone and ISO surface volume three-dimensional graphics; HF system considering the various line swing mode; HF system to guide wheel and guide wheel radius parameters have inverse calculation ability.

HF line cutting and integration system also has a network version, so that the training of schools throughout the University and college teaching handy.

HF system powerful:

HF programming and control integration system programming and processing in one, the most prominent feature is a powerful programming to facilitate the processing of a variety of different users can meet the needs of different situations. At the same time, the HF system has the most subtle consideration and maintenance, with user data backup, 3B text and G code editing, line drawing, single circle, two circle, circle, circle, three male common line (ellipse, involute, cycloid, sinusoidal line, Archimedes spiral, indexing gear, triangular spline or gears. Formula curve) block processing (mobile, replication, amplification, narrow, selection and rotation), breakpoint connection, line processing, multi line automatic clearance, correction and edge, variable trajectory, measurement, equal, shifting, explicit, explicit to track, on line processing, large taper machining power working memory and data security, anti wave interference, making complex image parameters (many types of gear and irregular graphics), conventional (Extended) processing mode, anti Trojan antivirus function, single board Parallel transmission, anti-interference G send data correction (processing and transmission); with 2NC, 3NC, TAC, TA1, 5NC, DXF, HGT, DAT, ISO and other file format to read and processing and conversion; 1 - 7 group machining of arbitrary set parameters (pulse width, pulse current, high frequency power converter, frequency value, value), tracking stability, process safety and high efficiency; single processing, anti single, cut off the number of inverse, arbitrary positioning processing, empty walk, on the edge of the image, zoom, processing time, real-time prompts, state display efficiency, the processing number display; parameter settings to easily complete the processing capability; comes at the same time Win98 driver and 10 DOS auxiliary way in software (USBDOS drive, buffer loading, virtual disk loading etc.); CD exquisite wizard to install the way to make your point to A.

The latest version of the HF is more stable, more powerful, with a material database to fill in, the angle of diversification, pulse transmission more diversified.
